Inputs
4 universal Y/CV, Pb/C, Pr (composite, s-Video and component) 1 Vpp/75O on RCA connectors; 2 UXGA on a 15-pin HD connector (VGA through UXGA); 2 HDMI connectors; 1 USB connector; For each UXGA input there is a corresponding (unbalanced) audio stereo input on a 3.5mm mini jack connector
Outputs
1 HDMI connector; 1 UXGA format on a 15-pin HD connector; 1 unbalanced audio stereo output (1V nom./50O) on RCA connectors; 1 digital stereo S/PDIF output (32kHz to 96kHz sample frequency/75O) on an RCA connector.
Compliance with HDMI Standard
Supports HDMI and HDCP.
OUTPUT RESOLUTION
Native HDMI, 640x480x60Hz, 640x480x75Hz, 800x600x50Hz, 800x600x60Hz, 800x600x75Hz, 1024x768x50Hz, 1024x768x60Hz, 1024x768x75Hz, 1280x768x50Hz, 1280x768x60Hz, 1280x720x60Hz, 1280x800x60Hz, 1280x1024x50Hz, 1280x1024x60Hz, 1280x1024x75Hz, 1366x768x50Hz, 1366x768x60Hz, 1400x1050x50Hz, 1400x1050x60Hz, 1600x1200x50Hz, 1600x1200x60Hz, 1680x1050x60Hz, 1920x1080x60Hz, 1920x1200x60Hz, 480px60Hz, 576px60Hz, 720px50Hz, 720px60Hz, 1080ix50Hz, 1080ix60Hz, 1080px50Hz, 1080px60Hz, 720x480x59.94Hz, 1280x720x59.94Hz, 1920x1080ix59.94Hz, 1920x1080x23.98Hz, 1920x1080x29.97Hz, 1920x1080x59.94Hz or custom.
CONTROL
Front panel buttons/OSD, IR remote control, RS-232 on a 9-pin D-sub connector.
ADDITIONAL CONTROLS
Picture-In-Picture: Video-in-Graphics (or vice versa), Picture-and-Picture or Split Screen (two images side-by-side), freeze, zoom, different selectable vertical refresh rates, video and audio ProcAmp control, output image scaling and aspect ratio change, EDID capture, text overlay, slide show.
POWER CONSUMPTION
100-240V AC, 50/60Hz, 30VA automatic power supply.
DIMENSIONS
19" x 9.3" x 1U W, D, H, rack mountable.
WEIGHT
3kg (6.6lbs) approx.
