Power Rating
800 W / 1600 W / 3200 W
Frequency Range
57 Hz - 20 kHz
Dimensions
(H x W x D) : 343 mm x 597 mm x 376 mm (13.5 in x 23.5 in x 14.8 in)
Frequency Response
75 Hz - 20 Hz
Coverage Pattern
100 x 15 nominal
Crossover Modes
Bi-amp / passive, externally switchable
Crossover Frequency
132 dB SPL peak 1.2 kHz
System Maximum SPL
Passive: 130 dB SPL peak , Bi-amp LF: 130 dB SPL peak
System Sensitivity (1w @ 1m
Passive: 95 dB SPL Bi-amp LF: 95 dB SPL Bi-amp HF: 114 dB SPL
LF Driver
1 x JBL 2262H 305 mm (12 in) Differential Drive« woofer with neodymium magnet, dual voice-coils, and dual magnetic gaps.
HF Driver
3 x JBL 2408J, 38 mm (1.5 in) voice-coil, neodymium compression driver
Nominal Impedance
Passive: 8 ohm Bi-amp LF: 8 ohm Bi-amp HF: 8 ohm
Enclosure
18 mm, 11-ply birch plywood
Suspension / Mounting
Optional VRX932LA-AF line array frame kit
Finish
Black DuraFlexÖ finish
Grille
Power coated, black, 16-guage perforated steel with with acoustically transparent foam
Input Connectors
Neutrik« Speakon« NL-4 (x2)
Optional Accessories
VRX932LA-AF: Suspension array frame
SS2-BK
Tripod speaker stand
SS3-BK
Satellite speaker pole, 41 in (1041 mm)
SS4-BK
Adjustable satellite speaker pole to be used with the SRX718S only
